I/O modules form the logical extension of control units. They increase the number of inputs and outputs or provide special functions.
They also simplify the wiring inside a mobile machine through the connection and control using the CAN bus. I/O modules are positioned close to the appropriate actuators and sensors. The position in the machine can be identified via hardware encoding; the modules can be configured using software.
- TriCore TC 1798 32 bit, 300 MHz
- 2 CAN interfaces (CAN 1 with Wake-up function), optional 1 LIN interface
- ESX CAN efficient safety (ECeS)
- 16 inputs
- 15 outputs
- 8 bit Microcontroller, 16MHz
- 64 kB Flash internal
- 2 kB EEPROM
- 1 CAN interface
- 4 A motor bridge
- Variant 1: 28 inputs
- Variant 2: 24 inputs / 4 outputs
- Variant 3: 20 inputs / 8 outputs
- Variant 4: 16 inputs / 12 outputs
- STM32F205 32 bit, 120 MHz
- 1 MB Flash
- 1 CAN interface
- 4 half bridges 10 A (can be combined into 2 full bridges)
- 32 kB EEPROM
- 4 inputs and 3 outputs
- Protocol: CANopen, CAN Layer 2-B
- Auxiliary Voltage: 8 … 32 V DC
- Baudrate: 250, 500 kbit/s
- Connection IOs: DT-4
- Power Connection:DT-18
- Input Signal Type: DI, DI/AI, DI/FRQ/CNT
- Output Signal Type: DO [4 A], PWM [4 A], PWM(i) [4 A]
